-60%
RG174 RF Coaxial Cable with SMA Female to SMA Male Right Angle Connector | Compact Flexible Cable for RF, GPS & Wireless Devices
RG174 RF Coaxial Cable with SMA Female to SMA Male Right Angle Connector | Compact Flexible Cable for RF, GPS & Wireless Devices
RG174 RF Coaxial Cable with SMA Female to SMA Male Right Angle Connector | Compact Flexible Cable for RF, GPS & Wireless Devices
RG174 RF Coaxial Cable with SMA Female to SMA Male Right Angle Connector | Compact Flexible Cable for RF, GPS & Wireless Devices
RG174 RF Coaxial Cable with SMA Female to SMA Male Right Angle Connector | Compact Flexible Cable for RF, GPS & Wireless Devices
RG174 RF Coaxial Cable with SMA Female to SMA Male Right Angle Connector | Compact Flexible Cable for RF, GPS & Wireless Devices
RG174 RF Coaxial Cable with SMA Female to SMA Male Right Angle Connector | Compact Flexible Cable for RF, GPS & Wireless Devices
  1. RG174 RF Coaxial Cable with SMA Female to SMA Male Right Angle Connector | Compact Flexible Cable for RF, GPS & Wireless Devices
  2. RG174 RF Coaxial Cable with SMA Female to SMA Male Right Angle Connector | Compact Flexible Cable for RF, GPS & Wireless Devices
  3. RG174 RF Coaxial Cable with SMA Female to SMA Male Right Angle Connector | Compact Flexible Cable for RF, GPS & Wireless Devices
  4. RG174 RF Coaxial Cable with SMA Female to SMA Male Right Angle Connector | Compact Flexible Cable for RF, GPS & Wireless Devices
  5. RG174 RF Coaxial Cable with SMA Female to SMA Male Right Angle Connector | Compact Flexible Cable for RF, GPS & Wireless Devices
  6. RG174 RF Coaxial Cable with SMA Female to SMA Male Right Angle Connector | Compact Flexible Cable for RF, GPS & Wireless Devices
  7. RG174 RF Coaxial Cable with SMA Female to SMA Male Right Angle Connector | Compact Flexible Cable for RF, GPS & Wireless Devices

RG174 RF Coaxial Cable with SMA Female to SMA Male Right Angle Connector | Compact Flexible Cable for RF, GPS & Wireless Devices

Price range: ₹399 through ₹899

Additional Offers
  • Flat 5% Off on Prepaid Order

The NETBOON RG174 RF Coaxial Cable with SMA Female to SMA Male Right Angle Connector is engineered for applications that require stable RF performance, compact routing, and secure connectivity. Made using premium RG174 flexible coax, it supports frequencies up to 3 GHz, offering dependable signal transmission with optimal impedance matching.

Its SMA Female and Right-Angle SMA Male connectors are crafted from nickel-plated brass with gold-plated contact pins, ensuring excellent conductivity, corrosion resistance, and stable locking in tight equipment spaces. The right-angle design makes this cable ideal for compact RF enclosures, wireless modules, GPS boards, IoT devices, test setups, and communication systems where straight connectors are difficult to manage.

Lightweight yet durable, the RG174 cable provides good shielding, flexible installation, and consistent performance, making it suitable for professional, industrial, and field-use applications. NETBOON ensures each cable is thoroughly tested for signal reliability and long-term use.

🟢 Key Features:

  • Connector Type: SMA Female to SMA Male Right Angle

  • Frequency Range: DC to 3 GHz

  • Impedance: 50 Ohm

  • Cable Type: RG174 Flexible Low Loss Coaxial Cable

  • Right-Angle Output: Ideal for tight or narrow installation spaces

  • Flexible Build: Easy cable routing without damaging conductors

  • Good Shielding: Reduces EMI/RFI interference

  • Durable Installation: UV-resistant PVC jacket for long life

  • Perfect For: GPS, RF testing, antennas, wireless modules, IoT boards

🟢 Technical & Mechanical Specifications:

Specification Details
Product Name NETBOON RG174 RF Coaxial Cable
Connector Type SMA Female to SMA Male Right Angle
Impedance 50 Ohm
Frequency Range DC – 3 GHz
Cable Type RG174 Flexible Coaxial Cable
Inner Conductor Copper-Clad Steel (CCS)
Shielding Tinned Copper Braid with PE Dielectric
Outer Jacket UV-Resistant PVC
VSWR ≤ 1.5:1
Return Loss ≥ 18 dB
Operating Temperature –40°C to +85°C
Connector Finish Nickel-plated brass with gold-plated pin
Applications GPS, RF Modules, Test Equipment, IoT Devices, Wireless Systems

🟢 Extended Compatibility:

✅ RF & Wireless Communication Modules
✅ GPS and GNSS Boards
✅ IoT & Embedded Systems
✅ Antenna Extensions & Router Interfaces
✅ Radio Frequency Test Instruments
✅ Lab & Field Communication Devices

🟢 Warranty Information:

6 Months Warranty – Quality Assured by NETBOON
Each unit is fully inspected and tested for signal accuracy, connector integrity, and long-term reliability, ensuring durable performance for demanding RF applications.

🟢 Bulk & OEM Inquiry:

Need custom length, bulk quantity, or OEM RF assemblies?
📞 Call/WhatsApp: +91-6266758816 / +91-9303369506
📧 Email: netboon15@gmail.com

We supply custom RF coax assemblies tailored for industrial, telecom, IoT, and research applications.

Cable Length

15CM, 30CM, 1M, 2M, 5M
