RG188 RF Coaxial Cable | BNC Male Right Angle to BNC Female Connector | Low-Loss High-Frequency Cable for CCTV, Test Labs & Communication Systems

Optimize your RF connections in compact and space-restricted environments with the NETBOON RG188 Coaxial Cable Assembly featuring BNC Male Right Angle to BNC Female Connector. Engineered for precision and reliability, this cable is ideal for oscilloscopes, CCTV networks, test benches, RF analyzers, SDR receivers, communication setups, and broadcast equipment requiring a secure and stable BNC extension.

The Right Angle BNC Male connector provides a convenient solution for tight installations, reducing strain on ports and enabling neat cable routing behind panels, instruments, or enclosure corners. The BNC Female connector serves as a reliable extension interface compatible with a wide range of video transmission lines, RF instruments, and monitoring devices. Together, the connectors ensure quick-locking, stable coupling in high-frequency applications.

Constructed using a silver-plated SCCS conductor, flexible dielectric material, and highly effective shielding, this RG188 assembly ensures minimal interference, consistent impedance, and low attenuation up to 3.0 GHz. NETBOON’s precision manufacturing provides robust performance suited for professional engineering labs, communication systems, and demanding industrial RF applications.

---

🟢 Technical & Mechanical Specifications

• Impedance: 50 ±2 Ω

• Capacitance: 29.4 pF/ft

• Max. Voltage: 1200V

• Max. Frequency: 3.0 GHz

• Conductor: Silver-plated copper-clad steel (SCCS), 7×0.17mm / 7×0.0067″

• Minimum Bend Radius: 12.7mm / 0.5″

---

🟢 Key Features

• BNC Male Right Angle to BNC Female connector configuration

• Space-efficient right-angle design for tight installations

• Low-loss RG188 cable for stable high-frequency performance

• Silver-plated SCCS conductor ensures strong signal conductivity

• Excellent shielding for noise-free RF transmission

• Ideal for CCTV, RF testing, SDR, broadcast, and instrumentation

---

🟢 Extended Compatibility

Suitable for oscilloscopes, CCTV systems, video monitoring lines, RF analyzers, SDR receivers, antennas, communication equipment, test instruments, and industrial RF setups.

---

🟢 Warranty Information

6 Months Warranty – NETBOON Quality Assured
Every RG188 cable is tested for shielding strength, continuity, impedance stability, and mechanical reliability. Backed by a 6-month replacement warranty.

---

🟢 Bulk & OEM Inquiry

Need custom lengths or bulk orders?
📞 Call/WhatsApp: +91-6266758816 / +91-9303369506
📧 Email: netboon15@gmail.com

NETBOON provides OEM manufacturing, custom RF cable assemblies, and bulk supply for telecom, IoT, labs, aerospace, and industrial RF applications.
